| Image Sensor | 2 MP CMOS |
| Shutter Time | PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s |
| Min. Illumination | 0.01 Lux @ (F1.6, AGC ON), 0 Lux with white light |
| Day & Night | 24/7 Color Imaging |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360° |
| Signal System | PAL/NTSC |
| Resolution | 1920 (H) × 1080 (V) |
| Frame Rate | TVI: 1080p@25fps/30fps CVI: 1080p@25fps/30fps AHD: 1080p@25fps/30fps CVBS: PAL/NTSC |
| Lens | 2.8 mm/3.6 mm fixed lens |
| Field of View | 2.8 mm, horizontal FOV: 102°, vertical FOV: 55°, diagonal FOV: 122° 3.6 mm, horizontal FOV: 84°, vertical FOV: 44°, diagonal FOV: 99° |
| Lens Mount | M12 |
| WDR (Wide Dynamic Range) | Digital WDR |
| White Light | Auto/Off |
| Image Mode | STD/HIGH-SAT |
| AGC | Yes |
| Day/Night Mode | Color |
| White Balance | Auto/Manual |
| AE (Auto Exposure) Mode | DWDR,BLC,HLC,Global |
| Noise Reduction | 2D DNR |
| Language | English |
| Function | Brightness, Contrast, Mirror, Sharpness, Smart Light, Saturation |
| Video Output | Switchable TVI/AHD/CVI/CVBS |
| Power Output | 12 VDC |
| Material | Plastic |
| Operating Conditions | -40°C to 45°C (-40°F to 113°F), Humidity: 90% or less (non-condensing) |
| Power Supply | 12 VDC±25% *You are recommended to use one power adapter to supply the power for one camera. |
| Consumption | Max. 2.3 W |
| White Light Range | Up to 20 m |
| Protection | IP66 |
