Zoom
Description
Camera
| Min. illumination | 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR |
| Shutter Time | PAL: 1/12.5 s to 1/50, 000 s NTSC: 1/15 s to 1/50, 000 s |
| Lens | 2.8 mm, 3.6 mm, 6 mm fixed lens |
| Lens Mount | M12 |
| Day & Night | ICR |
| Angle Adjustment | Pan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360° |
| Image Sensor | 8.29 MP CMOS |
| Signal System | PAL/NTSC |
| Frame Rate | TVI: 8MP@12.5fps, 8MP@15fps, 4MP@25fps, 4MP@30fps, 2MP@25fps, 2MP@30fps AHD: 8MP@15fps CVI: 8MP@12.5fps, 8MP@15fps CVBS: PAL/NTSC |
| Resolution | 3840 (H) × 2160 (V) |
| Horizontal Field of View | 102.9° (2.8 mm), 79° (3.6 mm), 44.7° (6 mm) |
| WDR (Wide Dynamic Range) | Digital WDR |
General
| Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F), humidity 90% or less (non-condensing) |
| Power Supply | 12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera. |
| Power Consumption | Max. 2.2 W |
| IR Range | Up to 30 m |
| Material | Plastic |
| Communication | HIKVISION-C |
| Dimensions | Φ 84.6 mm × 78.9 mm (Φ 3.33" × 3.11") |
| Weight | Approx. 150 g (0.33 lb.) |
Menu
| AGC | Yes |
| White Balance | Auto/Manual |
| Language | English |
| Image Mode | STD/HIGH-SAT |
| AE (Auto Exposure) Mode | Global/BLC/HLC/DWDR |
| Noise Reduction | 2D DNR |
| Function | Brightness, Sharpness, Smart IR |
| Day/Night Mode | Auto/Color/BW (Black and White) |
Interface
| Video Output | Switchable TVI/AHD/CVI/CVBS |
