| Lens Type | 2.8 mm, 3.6 mm, 6 mm fixed lens |
| Focal Length & FOV | 2.8 mm, horizontal FOV: 106.4°, vertical FOV: 57.9°, diagonal FOV: 124.6° 3.6 mm, horizontal FOV: 79.6°, vertical FOV: 43.5°, diagonal FOV: 93.7° 6 mm, horizontal FOV: 51.9°, vertical FOV: 30°, diagonal FOV: 58.8° |
| Lens Mount | M12 |
| Supplement Light Range | IR Distance: up to 25 m |
| Image Parameters Switch | STD/HIGH-SAT |
| Image Settings | Brightness,Mirror,Smart IR,Sharpness,AGC |
| Frame Rate | TVI: 1080P@30fps, 1080P@25fps AHD: 1080P@30fps, 1080P@25fps CVI: 1080P@30fps, 1080P@25fps CVBS: PAL/NTSC |
| Day/Night Mode | Auto/Color/BW (Black and White) |
| Wide Dynamic Range (WDR) | Digital WDR |
| Image Enhancement | DWDR,BLC,HLC,Global |
| Noise Reduction | 2D DNR |
| White Balance | Auto/Manual |
| Protection | IP66 |
| Min. Illumination | 0.01 Lux@(F2.0, AGC ON), 0 Lux with IR |
| Image Sensor | 2 MP CMOS |
| Signal System | PAL/NTSC |
| Shutter Time | PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s |
| Day & Night | IR Cut Filter |
| Angle Adjustment | Pan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360° |
| Max. Resolution | 1920 (H) × 1080 (V) |
| Audio | Built-in mic |
| Video Output | Switchable TVI/AHD/CVI/CVBS |
| Power | 12 VDC ± 25%, max. 2.7 W |
| Dimension | 58 mm × 61 mm × 158.6 mm (2.28 inch × 2.40 inch × 6.42 inch) |
| Weight | Approx. 160 g (0.35 lb.) |
| Operating Condition | -40 °C to 60 °C (-40 °F to 140 °F), humidity 90% or less (non-condensing) |
| Communication | Prama |
| Language | English |
| Protection Level | IP66 |
| Material | Plastic |
