| Image Sensor | 5 MP CMOS |
| Min. illumination | 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR |
| Shutter Time | PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
| Lens | 2.8 mm, 3.6 mm, 6 mm fixed lens |
| Lens Mount | M12 |
| Day & Night | ICR |
| Angle Adjustment | Pan: 0 to 355°, Tilt: 0 to 75°, Rotation: 0 to 355° |
| WDR (Wide Dynamic Range) | Digital WDR |
| Audio | Built-in mic |
| Frame Rate | TVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps CVI: 4MP@30fps, 4MP@25fps AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps CVBS: PAL/NTSC |
| Signal System | PAL/NTSC |
| Field of View | 2.8 mm, horizontal FOV: 85.5°, vertical FOV: 63.7°, diagonal FOV: 110.7° 3.6 mm, horizontal FOV: 80.1°, vertical FOV: 63.7°, diagonal FOV: 105.9° 6 mm, horizontal FOV: 57.1°, vertical FOV: 43.1°, diagonal FOV: 72.5° |
| Resolution | 2560 (H) × 1944 (V) |
| Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F), humidity 90% or less (non-condensing) |
| Power Supply | 12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera. |
| Power Consumption | Max. 3.7 W |
| Protection Level | IP67 |
| IR Range | Up to 25 m |
| Weight | Approx. 160 g (0.35 lb.) |
| Material | Plastic |
| Communication | HIKVISION-C |
| Dimensions | 58 mm × 61 mm × 158.6 mm (2.28" × 2.40" × 6.42") |
| AGC | Yes |
| White Balance | Auto/Manual |
| Language | English |
| Image Mode | STD/HIGH-SAT |
| Day/Night Mode | Auto/Color/BW (Black and White) |
| AE (Auto Exposure) Mode | DWDR/BLC/HLC/Global |
| Noise Reduction | 2D DNR |
| Function | Brightness, Sharpness, Mirror, Smart IR |
| Video Output | Switchable TVI/AHD/CVI/CVBS |
