| Day/Night Mode | Color |
| Noise Reduction | 2D DNR |
| White Balance | Auto/Outdoor/Global/Manual |
| White Light | Auto/Off |
| Image Mode | STD/HIGH-SAT/HIGHLIGHT |
| AGC | Yes |
| AE (Auto Exposure) Mode | DWDR,BLC,HLC,Global,HLS |
| Language | English |
| Function | Brightness,Contrast,Mirror,Defective Pixel Correction,Sharpness,Anti-Banding,Smart Light |
| Audio In | Built-in mic |
| Video Output | Switchable TVI/AHD/CVI/CVBS |
| Consumption | Max. 2.5 W |
| Dimension | 161.1 mm × 70 mm × 70 mm (6.34" × 2.76" × 2.76") |
| White Light Range | Up to 20 m |
| Material | Plastic |
| Communication | HIKVISION-C |
| Weight | Approx. 238 g (0.52 lb.) |
| Operating Conditions | -40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing) |
| Power Supply | 12 VDC ± 25%, *You are recommended to use one power adapter to supply the power for one camera. |
| Protection Level | IP67 |
| Signal System | PAL/NTSC |
| Min. Illumination | 0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light |
| Field of View | 2.8 mm, horizontal FOV: 102°, vertical FOV: 56°, diagonal FOV: 122° 3.6 mm, horizontal FOV: 80°, vertical FOV: 45°, diagonal FOV: 96° |
| Light Alarm | Solid Light Alarm (White Light) |
| Image Sensor | 3K CMOS |
| Shutter Time | PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s |
| Lens | 2.8 mm and 3.6 mm fixed focal lens |
| Lens Mount | M12 |
| Day & Night | 24/7 Color Imaging |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360° |
| Frame Rate | TVI: 3K@20fps, 4 MP@25fps/30fps, 1080p@25fps/30fps AHD: 5 MP@20fps, 4 MP@25fps/30fps CVI: 4 MP@25fps/30fps CVBS: PAL/NTSC |
| Resolution | 2960 (H) × 1665 (V) |
| WDR (Wide Dynamic Range) | Digital WDR |
