Interactive Panel
| Dimensions | 68 mm × 70 mm × 179.8 mm (2.68" × 2.76" × 7.08") |
| Weight | Approx. 358 g (0.79 lb.) |
| Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensing) |
| Power Supply | 12 VDC ± 25% |
| Power Consumption | Max. 3.9 W |
| IR Range | Up to 20 m |
| Communication | HIKVISION-C |
| Material | Metal |
| Ingress Protection | IP67 |
| White Light Range | Up to 20 m |
| PIR Angle and Range | Angle: 110°, Range:11 m |
| White Light | Alarm/Off |
| AGC | Yes |
| White Balance | Auto/Manual |
| Privacy Mask | 4 programmable privacy masks |
| Motion Detection | 4 programmable motion areas |
| Language | English |
| Image Mode | STD/HIGH-SAT |
| AE (Auto Exposure) Mode | WDR/BLC/HLC/Global |
| Noise Reduction | 3D DNR, 2D DNR |
| Day/Night Mode | Auto/Color/BW (Black and White) |
| Function | Brightness, Sharpness, Mirror, Smart IR |
| Video Output | 1 HD analog output |
| Alarm | 1 alarm out |
| Min. illumination | 0.003 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time | PAL: 1/25 s to 1/50, 000 sNTSC: 1/30 s to 1/50, 000 s |
| Lens | 2.8 mm, 3.6 mm fixed focal lens |
| Lens Mount | M12 |
| Day & Night | ICR |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 180°, Rotate: 0° to 360° |
| Slow Shutter | Max. 16 times |
| Resolution | 1920 (H) × 1080 (V) |
| Frame Rate | PAL: 1080p@25fps NTSC: 1080p@30fps |
| Horizontal Field of View | 103.5° (2.8 mm), 79.1° (3.6 mm) |
| WDR (Wide Dynamic Range) | ≥130 dB |
| Strobe Light Alarm | Yes |
