Interactive Panel
| Video Output | 1 HD analog output |
| Switch Button | TVI/AHD/CVI/CVBS |
| White Light | Up to 20 m |
| Material | Main Body: Metal Mounting Base: Plastic |
| Communication | Up the coax, Protocol: HIKVISION-C (TVI output) |
| Dimensions | Ø 109.82 mm × 85.56 mm ( Ø 4.32" × 3.37") |
| Weight | Approx. 336 g (0.74 lb.) |
| Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) |
| Power Supply | 12 VDC ±25% |
| Power Consumption | Max. 3 W |
| Protection Level | IP67 |
| Min. illumination | Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light |
| Shutter Time | PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
| Slow Shutter | Max. 16x |
| Lens | 3.6 mm, 6 mm fixed lens |
| Lens Mount | M16 |
| Day & Night | Color |
| Angle Adjustment | Pan: 0° to 360°; Tilt: 0° to 75°; Rotate: 0° to 360° |
| Synchronization | Internal synchronization |
| Frame Rate | PAL: 1080p@25fps NTSC: 1080p@30fps |
| WDR (Wide Dynamic Range) | 130 dB |
| Horizontal Field of View | 83.6° (3.6 mm), 52.8° (6 mm) |
| BLC (Backlight Compensation) | Yes |
| WDR | Yes |
| AGC | Yes |
| White Balance | Auto/Manual |
| Privacy Mask | 4 programmable privacy masks |
| Motion Detection | 4 programmable areas |
| Functions | Brightness, Sharpness, 3D DNR, Mirror, Smart light |
| HLC | Yes |
