| Lens Type | Fixed focal lens, 2.8 and 3.6 mm optional |
| Lens Mount | M12 |
| Focal Length & FOV | 2.8 mm, horizontal FOV: 106°, vertical FOV: 57°, diagonal FOV: 126° 3.6 mm, horizontal FOV: 83°, vertical FOV: 44°, diagonal FOV: 99° |
| Supplement Light Type | White Light |
| Supplement Light Range | Up to 20 m |
| Smart Supplement Light | Yes |
| Image Parameters Switch | STD/HIGH-SAT/HIGHLIGHT |
| Image Settings | Brightness, Contrast, Mirror, Sharpness, Anti-Banding, Saturation, AGC |
| Frame Rate | TVI: 1080P@25 fps/30 fps |
| Day/Night Mode | Color |
| Wide Dynamic Range (WDR) | ≥130 dB |
| Image Enhancement | BLC, HLC, Global, HLS |
| Noise Reduction | 3D DNR/2D DNR |
| White Balance | Auto/Manual |
| Privacy Mask | 4 programmable privacy masks |
| White Light | Auto/Off |
| Motion Detection | 4 programmable motion areas |
| Built-in Microphone | Yes |
| Alarm | Solid Light Alarm (White Light) |
| Video Output | 1 HD analog output |
| Power | 12 VDC ± 25%, max. 7.4 W *You are recommended to use one power adapter to supply the power for one camera. |
| Operating Condition | -10 °C to 40 °C (14 °F to 104 °F). Humidity 90% or less (non-condensing) |
| Language | English |
| Dimension | Ø123.7 × 110.8 (4.9" × 4.4") |
| Material | Plastic |
| Communication | HIKVISION-C |
| Weight | Approx. 290 g (0.6 lb.) |
| Max. Resolution | 1920 (H) × 1080 (V) |
| Signal System | PAL/NTSC |
| Min. Illumination | 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light |
| Image Sensor | 2 MP CMOS |
| Shutter Time | PAL: 1/25 s to 1/50, 000 s;NTSC: 1/30 s to 1/50, 000 s |
| Slow Shutter | Max. 16 times |
| Day & Night | 24/7 Color Imaging |
| Angle Adjustment | Pan: 0 to 350°, tilt: 0 to 75° *DO NOT adjust the angle of the main body or enclosure manually. |
