Description
Interface
| Video Output | 1 HD analog output |
General
| Material | Plastic |
| Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation) |
| Power Supply | 12 VDC ±15% |
| Power Consumption | Max. 4 W |
| IR Range | Up to 20 m |
Camera
| Min. Illumination | 0.02 Lux@(F1.2, AGC ON), 0 Lux with IR |
| Shutter Time | 1/25 (1/30) s to 1/50,000 s |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° |
| Signal System | PAL/NTSC |
| Lens | 2.8 mm, 3.6 mm |
| Horizontal Field of View | 103° (2.8 mm), 80.7° (3.6 mm), 50.1° (6 mm) |
| Lens Mount | M12 |
| Synchronization | Internal synchronization |
| Image Sensor` | 2 MP CMOS image sensor |
| Effective Pixels | 1920 (H) × 1080 (V) |
| Video Frame Rate | PAL: 1080p@25fps NTSC: 1080p@30fps |
Menu
| Image Mode | STD/HIGH-SAT |
| AGC | High/Medium/Low/Off |
| DWDR | Support |
| Language | English |
| Functions | Brightness, Sharpness, DNR, Mirror, Smart IR |
| D/N Mode | Auto/Color/BW (Black and White) |
| BLC | Support |
