| Installation | Wall mounting |
| Operation temperature | -25 °C to +60 °C (-13 °F to +140 °F) |
| Operation humidity | 10% to 90% (no condensing) |
| Color | White and blue |
| Material | PC+ABS |
| Dimension (W × H × D) | 220.5 × 205.2 × 46 mm (8.68" × 8.08" × 1.81"） |
| Protection level | IP65 |
RF
| RF Frequency | 433/868 MHz |
| RF method | Two-way communication |
| RF encryption | AES-128 |
| RF distance | 800 m (open area) |
| RF speed | 10 kbps/4.8 kbps |
| RF power | 10 dBm |
Electrical & battery
| Power | 4 CR123A Batteries (Battery powering mode by default) or 12 VDC |
| Consumption | Static consumption: ＜ 20 uA |
| Battery life span | 5 years in stand-by status |
Interface and component
| Learnt button | 1 |
| TAMPER switch | Front and rear panel tamper-proof |
| Indicator | Blue (on front panel), Green/Red (on PCB) |
| Buzzer | 1, Decibel: 110 dB |
