Hikvision Wired Shock Detector FPBG16DF

The Hikvision FPBG16DF (commonly engineered and cataloged under Hikvision's intrusion division, Pyronix BG16DF) is a professional, high-security Digital Acoustic Glass Break Detector.

Designed to monitor perimeter windows, glass doors, and conservatories, it uses an advanced internal omni-directional microphone and microprocessor signal analysis to isolate the unique sound signatures of breaking glass, ensuring comprehensive coverage with an exceptionally low rate of false alarms.

Key Technical Specifications

• Dual-Frequency Detection Architecture: Utilizes a mandatory 2-stage verification process to confirm a break. It first detects the low-frequency acoustic wave of the physical "flex" (impact stress on the glass pane), immediately followed by the high-frequency "shatter" (the sound of the glass fracturing).

• Signal Analysis Intelligence: Integrated microprocessor algorithms filter out background environmental noises (such as passing heavy trucks, thunder, or ringing telephones) that could otherwise trigger false alarms.

• Spatial Detection Coverage: Outfitted with an omni-directional electret microphone delivering a detection radius of 8 meters, resulting in a total 360-degree coverage diameter of 16 meters.

• Glass Variety Compatibility: Programmed to accurately detect breaches on a wide array of architectural panels including Float, Plate, Tempered, Wired, Laminated, Double-Glazed, and Leaded glass styles ranging from 2.4 mm to 6.4 mm in thickness.
