Description
Properties
| Category Type | UTP CAT 5E/ 6 |
| Transmission Distance | HDTVI/HDCVI/AHD 720P/300m (max); 1080P/250m(max); 3MP/4MP/5MP: 200m(max) |
| Transmission Signal | 1 channel |
Video Transmission Properties and Port
| Coaxial Video Connector | Push-terminal |
| Compatible Format | HDTVI/HDCVI/AHD |
| Resolution | 720P/1080P/3MP/4MP/5MP |
| Ant-interference | >60db |
Protection
| ESD | 1a contact discharge electricity level3 1b air discharge electricity level3 Per: IEC61000-4-2 |
| Coaxial Cable Connector | 2KV(common-code) Per:IEC61000-4-5 |
| UTP Cable Connector | 2KV(different-code), 2KV(common-code) Per:IEC61000-4-5 |
Impedance
| BNC Male | 75 ohms |
| UTP Cable | 100 ohms |
Physical Properties
| Shell | ABS |
| Color | Black |
| Dimensions ( L x W x H ) | 39 x 19 x 17mm |
| Weight | 38.6 g |
Stability
| MTBF | >10000 h |
| Operating Temperature | -10-55ºC |
| Storage Temperature | -20-70ºC |
Environmental
| Humidity | 0-95% (non-condensing) |
