Description
Detection performance
| Detection range | 12 m |
| Detection angle | 85.9° |
| Velocity range | 0.3 to 2 m/s |
| Sensitivity adjustment | High, Auto, Low |
| Pet Immunity | Up to 10kg (with optional pet mask) |
| Digital Temperature Compensation | Support |
| Creep Zone Protection | Support |
| White Light Filter | 6500 lux |
| Microwave Frequency | 24 Ghz (24.15 Ghz to 24.25 Ghz) |
Electrical characteristics
| Power Consumption | 17 mA Max |
| Typical Voltage | standard: 12 VDC |
| Power supply | 9 to 16 VDC |
General
| Bracket | Optional wall & ceiling accessory |
| Dimension(W × H × D) | 65.7 mm (2.59 ") × 103.8 mm (4.09 ") × 45.5 mm (1. 79 ") |
| Operation humidity | 10% to 90% |
| Installation height | 1.8 m to 2.4 m |
| Installation method | Wall-mounted or Ceiling-mounted |
| Operation temperature | -10 °C to 55 °C (14 °F to 131 °F) |
| Color | White |
| Weight | 99g (3.5 oz) |
| Application scenario | Indoor |
| Storage Temperature | -20 °C to 60 °C (-4 °F to 140 °F) |
Software features
| Sealed Optics | Support |
| Tamper-Proof | Front |
Hardware features
| Indicator | Green(PIR) Orange(Microwave) Blue(Alarm) |
