Description
Wireless transmission
| RF frequency | 433 MHz |
| RF method | Two way communication |
| Wireless security | AES-128 |
| RF modulation | 2GFSK |
| RF distance | 800 m |
Electrical characteristics
| Power supply | AC 100 V to 240 V, 50/60 HZ |
| Operation humidity | 10％ to 90％ |
| Operation temperature | -10 °C to 55 °C |
General
| Installation method | Wall Mounting or Inside 86 box |
| Dimension(W x H x D) | 38 x 25 x 18 mm |
| Shell material | Plastic |
| Color | White |
| Weight | 31.5 g |
Software features
| Scenario setting | By Alarm, By Operation, By Fault, By Schedule, By Manual |
| Learning button | 1, For register |
Hardware features
| Serial port | 1, for debug |
Device management
| Relay output | 1, NO/NC (AC 100 to 240 V, Max 13A） |
Display
| LEDs status | 3, Register/Signal (Green/Red), Power (Green), Relay Status (Blue) |
