Description
Wireless transmission
| RF frequency | 433MHz |
| RF method | Two-way communication |
| RF modulation | 2GFSK |
| RF distance | 1300m |
Electrical characteristics
| Power supply | 3 CR123 |
| Operation humidity | 10%~90% |
| Operation temperature | –10℃ ~ 55℃ |
| Power consumption | Quiescent current: 40.29 uA Max current: 47.85mA Voltage: 3 VDC |
| Battery life span | Up to 5 years (standby time) |
General
| Installation method | Put inside Wireless Ready Detector |
| Weight | 35g(Without Battery), 90g(With Battery) |
| Dimension(WxHxD) | 102*41*20mm |
Hardware features
| Alarm input | 1 Alarm, 1 Tamper |
| 3.3v Output | 1, up to 10mA |
| Serial port | 1 |
| Power switch | 1 |
| Alarm output | 1 PGM, AM/Output |
Display
| Indicator | 3: Alarm/Tamper（Red）, Fault（Amber）, Signal Strength（Green/Red） |
