Description
General
| Weight | 83g |
| Operation Temperature | -10 °C to 55 °C (14 °F to 131 °F) |
| Storage Temperature | -20 °C to 60 °C (-4 °F to 140 °F) |
| Operation Humidity | 10% to 90% |
| Dimension(WxHxD) | 38.8mm × 107.0mm × 24.5mm |
| Application Scenario | Indoor |
| Mounting Method | Wall,Ceiling |
Detection Performance
| Detection Method | Acoustic Sensor |
| Sensitivity | 2m,4m,6m,8m |
| Detection Range | 8m |
| Detection Angle | 120° |
| Glass Type | Float,Plate,Tampered,Wired,Laminated Leaded,Double Glazing |
| Glass Thickness | 2.4mm to 6.4mm |
| Glass Size | 0.3m x 0.3m to 3m x 3m |
Feature
| Signal Strength Indicator | Support |
| Environment Temperature Indicator | Support |
| Digital Processing | Support |
| Tamper Protection | Front,Rear |
Transmission
| Transmission Technology | Tri-X Wireless |
| Transmission Frequency | 433MHz |
| Transmission Security | AES-128 Encryption |
| Transmission Range(Free Space) | 1Km |
| Frequency Hopping | Support |
| Enrolling Method | Power up,Remote ID,QR Code |
| Transmission Method | Two-Way RF Wireless |
Electrical Characteristics
| Standard Battery Life | Up to 5 years (standby time) |
| Battery Type | CR123A × 2 |
| Power Supply | Battery Powered |
| Typical Voltage | 3V |
Interface
| Power Switch | Power Up Enrolling |
| Alarm Input | Normally Closed,Normally Open,Impulse Count |
| LED Indicator | Blue(Alarm) |
