Description
Network
| Remote connection | 64 |
| Network protocol | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
| Total bandwidth | 72 Mbps total bandwidth |
| Network interface | 1, RJ45 10M/100M self-adaptive Ethernet interface |
General
| Power supply | 12 VDC, 1.5 A |
| Working temperature | -10 °C to 55 °C (14 °F to 131 °F) |
| Working humidity | 10% to 90% |
| Consumption (without HDD) | ≤ 12 W |
| Dimensions (W × D × H) | 200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch) |
| Weight (without HDD) | ≤ 0.8 kg (1.8 lb) |
Recording
| Video compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Encoding resolution | When 1080p Lite mode is not enabled: 720p/WD1/4CIF/VGA/CIF When 1080p Lite mode is enabled: 1080p Lite/720p/WD1/4CIF/VGA/CIF |
| Frame rate | Main stream: When 1080p Lite mode is not enabled: For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) When 1080p Lite mode is enabled: 1080p Lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) Sub-stream: 4CIF/2CIF@6fps; CIF/QVGA/QCIF@25fps (P)/30fps (N) |
| Video bit rate | 32 Kbps to 4 Mbps |
| Dual stream | Support |
| Stream type | Video, Video & Audio |
| Audio compression | G.711u |
| Audio bit rate | 64 Kbps |
Certification
| FCC | Part 15 Subpart B, ANSI C63.4 |
| CE | EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 55024 |
Video and Audio
| Turbo HD input | 1080p25, 1080p30, 720p25, 720p30 |
| HDMI output | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA output | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Video output mode | HDMI/VGA simultaneous output |
| IP video input | 2-ch (up to 10-ch) Up to 1080p resolution Support H.265+/H.265/H.264+/H.264 IP cameras |
| Analog video input | 8-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| AHD input | 1080p25, 1080p30, 720p25, 720p30 |
| HDCVI input | 1080p25, 1080p30, 720p25, 720p30 |
| CVBS input | Support |
| Audio input | 1-ch, RCA (2.0 Vp-p, 1 KΩ) 8-ch via coaxial cable |
| Audio output | 1-ch, RCA (Linear, 1 KΩ) |
| Two-way audio | Reuse the first audio input |
| Synchronous playback | 8-ch |
Auxiliary interface
| Alarm in/out | N/A |
| SATA | 1 SATA interface |
| Capacity | Up to 6 TB capacity for each disk |
| USB interface | Rear panel: 2 × USB 2.0 |
