Description
General
| Appearance Color | Black (Included), Gold (Optional), Silver (Optional), White (Optional) |
| Audio | 1 Buzzer and 1 Loudspeaker |
| Card Reading Distance | 0 to 4.5cm |
| Card Reading Mode | Supports Mifare Card, Including Cards with Special Shapes; Supports Reading Card in Metal Environment |
| Card Reading Response Duration | < 1 s |
| Communication Interface | TCP/IP, RS-485 (For Secure Door Control Unit), Wiegand Output (W26/W34) and Input (Wiegand 26/34) |
| Dimension (L × W × H) | 205 mm × 76.5 mm × 37 mm (8.07" × 3.01" × 1.46") |
| External Card Reader | Standard Wiegand26/34 |
| FAR(False Accept Rate) | ≤ 0.001 % |
| Fingerprint Authentication Duration | < 1 s |
| Fingerprint Capacity | Up to 3000 Fingerprints; Up to 10 Fingerprints for Each Person |
| Fingerprint Comparing Mode | 1:1 and 1:N, N=3000 |
| Fingerprint Recognizer | Optical Fingerprint Recognizer Module |
| FRR (False Rejection Rate) | ≤ 0.01 % |
| Input Interface | Exit Button × 1, Door Sensor × 1 and Alarm Input × 1 |
| Keyboard | Keyboard (Back Light) |
| LED Indicator | Power/Status (Red/Green) |
| Operating System | Linux |
| Output Interface | Relay (Lock Output) × 1, and Alarm Output × 1 |
| Power Supply | 12 VDC/2 A |
| Reset Key | × 1 |
| Storage | Up to 3000 Valid Cards; Up to 100,000 Event Records; Up to 150,000 Attendance Records |
| Temper-Proof | Support |
| Transmission Rate | TCP/IP: 10/100Mbps, Self-adaptive; RS485: 19200 bps-N-8-1 |
| Wiegand Interface | Output: Wiegand 26/34; Input: Wiegand 26/34 |
| Wi-Fi | Support |
| Working Humidity | 10% to 90% (No Condensing) |
| Working Temperature | -10 °C to 55 °C (14 ° F to 131 ° F) |
