Description
Camera
| Min. illumination | 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR |
| Shutter Time | PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
| Lens | 2.8 mm, 3.6 mm, 6 mm fixed lens |
| Lens Mount | M12 |
| Day & Night | ICR |
| Angle Adjustment | Pan: 0 to 360°, Tilt: 0 to 90°, Rotation: 0 to 360° |
| Signal System | PAL/NTSC |
| Resolution | 1920 (H) × 1080 (V) |
| Field of View | 2.8 mm, horizontal FOV: 101°, vertical FOV: 60°, diagonal FOV: 122° 3.6 mm, horizontal FOV: 79.6°, vertical FOV: 43.5°, diagonal FOV: 93.7° 6 mm, horizontal FOV: 51.9°, vertical FOV: 30°, diagonal FOV: 58.8° |
| WDR (Wide Dynamic Range) | Digital WDR |
| Frame Rate | TVI: 1080P@30fps, 1080P@25fps CVI: 1080P@30fps, 1080P@25fps AHD: 1080P@30fps, 1080P@25fps CVBS: PAL/NTSC |
General
| Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F), humidity 90% or less (non-condensing) |
| Power Supply | 12 VDC ± 25% |
| Power Consumption | Max. 3 W |
| Protection Level | IP67 |
| IR Range | Up to 30 m |
| Material | Metal |
| Communication | HIKVISION-C |
| Dimensions | 57.9 mm × 60.9 mm × 138.8 mm (2.28" × 2.39" × 5.47") |
| Weight | Approx. 257 g (0.57 lb.) |
Menu
| AGC | Yes |
| White Balance | Auto/Manual |
| Language | English |
| Image Mode | STD/HIGH-SAT |
| AE (Auto Exposure) Mode | DWDR/BLC/HLC/Global |
| Noise Reduction | 2D DNR |
| Function | Brightness, Sharpness, Smart IR |
| Day/Night Mode | Auto/Color/BW (Black and White) |
Interface
| Video Output | Switchable TVI/AHD/CVI/CVBS |
