| Frame Rate | TVI: 1080p @ 25 fps/30 fps CVI: 1080p @ 25 fps/30 fps AHD: 1080p @ 25 fps/30 fps CVBS: PAL/NTSC |
| Min. Illumination | 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light |
| Shutter Time | PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s |
| Slow Shutter | Max. 16 times |
| Lens | 2.8 mm, 3.6 mm fixed focal lens |
| Field of View | 2.8 mm, horizontal FOV: 98°, vertical FOV: 52°, diagonal FOV: 116° 3.6 mm, horizontal FOV: 77°, vertical FOV: 42°, diagonal FOV: 91° |
| Lens Mount | M12 |
| Light Alarm | Solid Light Alarm (White Light) |
| Day & Night | Color |
| WDR (Wide Dynamic Range) | ≥130 dB |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360° |
Interface
| Audio In | Built-in mic |
| Video Output | Switchable TVI/AHD/CVI/CVBS |
General
| Consumption | Max. 3.0 W |
| Dimension | 161.1 mm × 70 mm × 70 mm (6.34" × 2.76" × 2.76") |
| White Light Range | Up to 20 m |
| Material | Metal |
| Communication | HIKVISION-C |
| Weight | Approx. 388 g (0.86 lb.) |
| Operating Conditions | -40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing) |
| Power Supply | 12 VDC ± 25%, *You are recommended to use one power adapter to supply the power for one camera. |
| Protection Level | IP67 |
Camera
| Resolution | 1920 (H) × 1080 (V) |
Menu
| Image Mode | STD/HIGH-SAT/HIGHLIGHT |
| Day/Night Mode | Color |
| AE (Auto Exposure) Mode | WDR, BLC, HLC, Global, HLS |
| Noise Reduction | 3D DNR/2D DNR |
| Function | Brightness, Contrast, Mirror, Defective Pixel Correction, Sharpness, Anti-Banding, Smart Light |
| White Light | Auto/Off |
| AGC | Yes |
| White Balance | Auto/Manual |
| Privacy Mask | 4 programmable privacy masks |
| Motion Detection | 4 programmable motion areas |
| Language | English |
