General
| Audio | 1 buzzer, 1 loudspeaker |
| Card Reading Distance | 0 to 3.5 cm |
| Card Reading Mode | EM card (support metal environment) |
| Communication Interface | TCP/IP, EHome |
| Dimension (L × W × H) | 140 mm × 155 mm × 30 mm (5.51" × 6.01" × 1.18") |
| FAR(False Accept Rate) | 1.0000000000000001E-5 |
| Fingerprint Authentication Duration | 1:N recognition duration( up to 1000 fingerprints ) < 1s |
| Fingerprint Capacity | Up to 1000 fingerprints |
| Fingerprint Recognizer | Optical fingerprint recognizer module |
| FRR (False Rejection Rate) | 1E-3 |
| Input Interface | Exit button x 1, doorbell output x 1 |
| Installation | Wall mounting (with gang box or without gang box) |
| LCD Screen | 2.4-inch LCD display screen |
| Operating System | Linux |
| Output Interface | Relay (lock output) × 1, doorbell output × 1 |
| Power Supply | 12 VDC/1 A |
| Storage | Up to 1000 users, 1000 valid cards, 100,000 records, and 50,000 attendance tables |
| Transmission Rate | TCP/IP: 10/100Mbps self-adaptive |
| USB | USB 2.0 |
| Working Humidity | 10% to 90% (No condensing) |
| Working Temperature | -10 °C to 55 °C (14 °F to 131 °F) |
