General
| Storage | Up to 800 Valid Cards; Up to 50,000 Event Records; Up to 150,000 Attendance Records (Swiping Card is Not Available for DS-K1A802F-1) |
| Fingerprint Capacity | Up to 800 Fingerprints; Up to 10 Fingerprints for Each Person |
| Fingerprint Comparing Mode | 1:1 and 1:N, N=3000 |
| Card Reading Response Duration | < 1 s |
| Fingerprint Authentication Duration | < 1 s |
| FAR(False Accept Rate) | ≤0.001% |
| FRR (False Rejection Rate) | ≤0.01% |
| Fingerprint Recognizer | Optical Fingerprint Recognizer Module |
| External Card Reader | |
| Card Reading Mode | Supports EM Card, Including Cards with Special Shapes; Supports Reading Card in Metal Environment |
| Card Reading Distance | 0 to 5cm |
| Lithium Battery | |
| Transmission Rate | LAN: 10/100 Mbps Self-adaptive |
| Keyboard | Physical Keys (No Back Light) |
| Reset Key | |
| Communication Interface | |
| Wi-Fi | Not Support |
| Wiegand Interface | |
| Input Interface | |
| Output Interface | |
| USB | USB2.0, Type A |
| LCD Screen | 2.8-inch 320 x 240 LCD-TFT Display Screen |
| Audio | 1 Buzzer, 1 Loudspeaker |
| LED Indicator | |
| Network interface | |
| Power Supply | 12 VDC/1 A |
| Working Temperature | -10 ° C to 55 ° C (14 ° F to 131 ° F) |
| Working Humidity | 10% to 90% (No Condensing) |
| Application Situation I | Indoor |
| Water-Proof | |
| Temper-Proof | |
| Appearance Color | Black (Included), Rose Gold (Optional), Silver (Optional), White (Optional) |
| Dimension (L × W × H) | 140 mm × 155 mm × 30 mm (5.51" × 6.01" × 1.18") |
| Installation | Surface Mounting, Metal Door Mounting, Desk Stand |
| Operating System | Linux |
