Description
Decoding
| Decoding format | H.265/H.265+/H.264/H.264+/MPEG4 |
| Synchronous playback | 16-ch |
| Capability | 2-ch @ 8 MP (25fps) / 4-ch @ 4MP (30fps) / 8-ch @ 1080p (30fps) |
| Recording resolution | 8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
General
| Power supply | 100 to 240 VAC |
| Working temperature | -10 to +55° C (14 to 131° F) |
| Working humidity | 10 to 90 % |
| Chassis | 385 mm chassis |
| Power | ≤ 280 W |
| Consumption(without hard disk) | ≤ 15 W (without enabling PoE) |
| Dimensions (W × D × H) | 385 × 315× 52 mm (15.2" × 12.4" × 2.0") |
| Weight (without hard disk) | ≤ 3 kg (6.6 lb) |
Video/ Audio input
| Outgoing bandwidth | 160 Mbps |
Video/Audio output
| HDMI output resolution | 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz,1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 ×768/60Hz |
| VGA output resolution | 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 ×768/60Hz |
| Audio output | 1-ch, RCA (Linear, 1 KΩ) |
Network management
| Network protocols | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
Hard disk
| SATA | 2 SATA interfaces |
| Capacity | Up to 6TB capacity for each HDD |
External interface
| Two-way audio | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Network interface | 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| USB interface | Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0 |
| Alarm in/out | 43834 |
POE (without hard disk)
| Interface | 16, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
| Power | ≤ 200 W |
| Supported standard | IEEE 802.3 af/at |
