Description
Network
| Remote connection | 16 |
| Network protocol | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS |
| Network interface | 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
Decoding
| Decoding format | H.265+/H.265/H.264+/H.264 |
| Synchronous playback | 4-ch |
| Capability | 1-ch@8 MP (30 fps)/5-ch@1080p (30 fps) |
| Stream type | Video, Video & Audio |
| Audio compression | G.711ulaw/G.711alaw/G.722/G.726 |
| Recording resolution | 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF |
General
| Power supply | 48 VDC, 1.3 A |
| Working temperature | -10 °C to 55 °C (14 °F to 131 °F) |
| Working humidity | 10% to 90% |
| Dimension (W × D × H) | 320 × 240 × 48 mm (12.6" × 9.4" × 1.9") |
| Weight (without HDD) | ≤ 1 kg (2.2 lb) |
| Consumption (without HDD and PoE off) | ≤ 10 W |
PoE
| Interface | 4, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
| Power | ≤ 50 W |
| Supported standard | IEEE 802.3 af/at |
Video and Audio
| Outgoing bandwidth | 80 Mbps |
| HDMI output | 1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz |
| VGA output | 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz |
| Video output mode | HDMI/VGA simultaneous output |
| CVBS output | N/A |
| Audio output | 1-ch, RCA (Linear, 1 KΩ) |
| Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input) |
| IP video input | 4-ch Up to 8 MP resolution |
| Incoming bandwidth | 40 Mbps |
Auxiliary Interface
| SATA | 1 SATA interface |
| Capacity | Up to 8 TB capacity for each disk |
| USB interface | Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0 |
Certification
| FCC | Part 15 Subpart B, ANSI C63.4-2014 |
