Description
General
| Net weight | 0.565 kg (1.25 lb) |
| Gross weight | 1.24 kg (2.73 lb) |
| Dimension (L × H × D) | 197 mm × 114.2 mm × 42.2 mm (7.76” × 4.50” × 1.66”) |
| Power source | 120 W |
| Max. power consumption | 120 W |
| Power consumption in idle | < 10 W |
| Shell | Metal material, fan-free design |
| Operating temperature | -30 °C to 65 °C (-22 °F to 149 °F) |
| Storage temperature | -40 °C to 85 °C (-40 °F to 185 °F) |
| Operating humidity | 5% to 95% (no condensation) |
| Storage humidity | 5% to 95% (no condensation) |
| Power supply | 48 to 57 VDC, 2.5 A Max. |
Dialing function
| Long range | Ports 7 and 8: up to 300 m. |
| Port isolation | Ports 1 to 8: port isolation mode to improve network security. |
| PoE watchdog | Ports 1 to 8: auto detect and restart the cameras that do not respond. |
Approval
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000- 3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM(AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016) |
Network parameters
| Port number | 6 × 100M PoE ports, 2 × Hi-PoE port, 1 × gigabit RJ45 port and 1 × gigabit SFP fiber optical port |
| Ports for long-distance transmission | Ports 7 and 8 |
| Working mode | Standard mode (default), Extend mode, Isolation mode, PoE watchdog mode |
| Port type | RJ45 port, full duplex, MDI/MDI-X adaptive |
| Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z and IEEE 802.3ab |
| Forwarding mode | Store-and-forward switching |
| MAC address table | 2 K |
| Switching capacity | 5.6 Gbps |
| Packet forwarding rate | 4.1664 Mpps |
| Internal cache | 1.0 Mbits |
PoE power supply
| Hi-PoE port | Ports 1 and 2 |
| PoE standard | Ports 1 and 2: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt Ports 3 to 8: IEEE 802.3af, IEEE 802.3at |
| PoE power pin | Ports 1, 2, 7 and 8: Ethernet cables 1/2/3/6 and 4/5/7/8 provide power supply simultaneously. Ports 3 to 6: Ethernet cables 1/2/3/6 provide power supply. |
| PoE port | Ports 3 to 8 |
| Max. port power | Ports 1 and 2: 90 W Ports 3 to 8: 30 W |
| PoE power budget | 110 W |
