General
| Weight | 0.6 kg (1.32 lb) |
| Shell | Metal material, fan-free design |
| Dimensions (L × H × D) | 217.6 mm × 27.8 mm × 108.55 mm (8.6” × 1.1” × 4.3”) |
| Operating temperature | 0˚C to 40˚C (32˚F to 104˚F) |
| Storage temperature | –40˚C to 85˚C (–40˚F to 185˚F) |
| Operating humidity | 5% to 95% (no condensation) |
| Storage humidity | 5% to 95% (no condensation) |
| Power supply | 48 VDC, 2.5 A |
| Power consumption | 120 W |
Network parameters
| Port type | RJ45 port, full duplex, MDI/MDI-X adaptive |
| Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3z |
| Forwarding mode | Store-and-forward switching |
| MAC address table | 4 K |
| Switching capacity | 20 Gbps |
| Packet forwarding rate | 14.88 Mpps |
| Internal cache | 1.5 Mbits |
PoE power supply
| PoE standard | IEEE 802.3af, IEEE 802.3at |
| PoE power pin | Support 4-core power supply, and Ethernet cable 1/2/3/6 provide power supply. |
| PoE port | Ports 1 to 8 |
| Max. port power | 30 W |
| PoE power budget | 110 W |
| Max. power consumption | 120 W |
