Description
Mechanical structure
| Shell | Metal material, fan-free design |
| weight | 0.35 kg (0.77 lb) |
| Dimensions (L × H × D) | 170 mm × 27.6 mm × 93.1 mm (6.7” × 1.1” × 3.7”) |
Environment
| Operating temperature | 0 ˚C to 40 ˚C (32 ˚F to 104 ˚F) |
| Storage temperature | –40 ˚C to 85 ˚C (–40 ˚F to 185 ˚F) |
| Relative humidity | 5% to 95% (no condensation) |
Power supply
| Power supply specification | 48 VDC, 1.35 A |
Network parameters
| Processing type | Store-and-forward switching |
| Ports with high priority | 1 to 2 ports |
| Ports for long-distance transmission | 1 to 8 ports |
| Exchange capacity | 1.8 Gbps |
| Standard | IEEE802.3, IEEE802.3u, IEEE802.3x |
| MAC address table | 2 K |
| Packet forwarding rate | 1.339 Mpps |
| Internal cache | 1 Mbits |
PoE power supply
| Power supply standard | IEEE 802.3af, IEEE 802.3at |
| Power supply cable core | Supports 8-core power supply, Ethernet cable 1/2/3/6 and 4/5/7/8 provide simultaneous power supply |
| Max. machine power | 60 W |
| PoE port | 1 to 8 |
| Max. port power | 30 W |
