Description
Port
| QoS | Supported on ports 1 and 2. |
| Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Forwarding method | Store-and-forward |
| Flow control | Back-pressure flow control in IEEE 802.3x full duplex |
| MAC address table | 1 K |
| Switching capacity | 1 Gbps |
| Packet forwarding rate | 0.744 Mpps |
| Priority queue | 2 |
Environment
| Operating temperature | (0 - 40) °C |
| Storage temperature | (-40 - 70) °C |
| Operating humidity | (10 – 90) % RH, non-condensing |
| Storage humidity | (5 – 90) % RH, non-condensing |
Physical appearance/structure
| Appearance | 0.6 mm sheet of galvanized metal without electric fan |
| Weight | 0.141 kg |
| Dimension | 100 mm × 100 mm × 26 mm |
| Mounting type | Desktop / wall mounting |
Other parameters
| LED indicator | Link/Act LED indicators, PoE LED indicator, Power LED indicator |
Power Supply
| Power input | 48 V DC, 0.8 A |
| Reverse connection protection | Supported |
| Power consumption | < 38 W |
