Zoom
Description
Camera
| Min. illumination | 0.005 Lux@(F1.2, AGC ON), 0 Lux with IR |
| Shutter Time | PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
| Slow Shutter | Max. 16 times |
| Lens | 2.8 mm, 3.6 mm, 6 mm |
| Lens Mount | M12 |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° |
| Synchronization | Internal synchronization |
| WDR | ≥ 120 dB |
| Image Sensor | 2.0 megapixel progressive scan CMOS |
| Appearance | Turret |
| Signal System | PAL/NTSC |
| Video Frame Rat | PAL: 1080p@25fps NTSC: 1080p@30fps |
| Resolution | 1920 (H) ×1080 (V) |
| Horizontal Field of View | 106°(2.8 mm), 82°(3.6 mm), 51°(6 mm) |
General
| Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) |
| Power Supply | 12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera. |
| Power Consumption | Max. 4.6 W |
| IR Range | Up to 30 m |
| Material | Plastic |
| Dimensions | Φ 85.8 mm × 70 mm (Φ 3.38" × 2.76") |
| Weight | Approx. 127 g (0.28 lb.) |
Menu
| AGC | High/Medium/Low |
| D/N Mode | Auto/Color/BW (Black and White) |
| 3D DNR | Level 1 to 9 |
| Language | English |
| Functions | Brightness, Sharpness, 3D DNR, Mirror, Smart IR |
| Image Mode | STD/HIGH-SAT |
| HLC (Highlight Compensation) | Yes |
| BLC (Backlight Compensation) | Yes |
| WDR | Yes |
Interface
| Video Output | 1 HD analog output |
| Switch Button | TVI/AHD/CVI/CVBS |
