Description
Camera
| Image Sensor | 1MP CMOS Image Sensor |
| Effective Pixels | 1296(H)*732(V) |
| Min. illumination | 0.1 Lux @ (F1.2,AGC ON),0 Lux with IR |
| Shutter Time | 1/25(1/30)s to 1/50,000s |
| Lens | 2.8mm, 3.6mm,optional Angle of View: 70.9°(3.6mm), 92°(2.8mm) |
| Lens Mount | M12 |
| Day & Night | ICR |
| Angle Adjustment | Pan: 0 - 360°, Tilt: 0 - 180°, Rotation: 0 - 360° |
| Synchronization | Internal synchronization |
| Video Frame Rate | 720p@25fps/720p@30fps |
| HD Video Output | 1 Analog HD output |
| S/N Ratio | ＞62dB |
| Signal System | PAL/NTSC |
General
| Operating Conditions | -40 °C – 60 °C (-40 °F – 140 °F), Humidity 90% or less (non-condensing) |
| Power Supply | 12 VDC±15% |
| Power Consumption | Max. 4W |
| IR Range | Up to 20m |
| Dimensions | Φ70×151 mm (Φ2.76” ×5.94”) |
| Weight | 300 g |
| Protection Level | IP66 |
