Description
Camera
| Min. illumination | 0.01 Lux@(F1.2,AGC ON),0 Lux with IR |
| Shutter Time | 1/25 (1/30) s to 1/50,000 s |
| Lens | 2.8 mm, 3.6 mm, 6 mm fixed lens |
| Lens Mount | M12 |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360° |
| Synchronization | Internal synchronization |
| Image Sensor | 2MP CMOS Image Sensor |
| Signal System | PAL/NTSC |
| Resolution | 1920 (H) × 1080 (V) |
| Horizontal Field of View | 103° (2.8 mm), 82.2° (3.6 mm), 54° (6 mm) |
| Frame Rate | PAL: 1080p@25fps NTSC: 1080p@30fps |
General
| Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F), Humidity 90% or less (non-condensation) |
| Power Supply | 12 VDC±15% |
| Power Consumption | Max. 4 W |
| IR Range | Up to 20 m |
| Material | Plastic |
| Dimensions | Φ 70 mm × 154.5 mm ( 2.76" × 6.08") |
| Weight | Approx. 400 g (0.88 lb.) |
| Ingress Protection | IP66 |
Menu
| AGC | Low/middle/high |
| Language | English |
| Functions | Brightness, Sharpness, DNR, Mirror |
| Day/Night Mode | Smart/color/BW(Black and White) |
| Backlight Compensation | Yes |
| DWDR | Yes |
Interface
| Video Output | 1 HD analog output |
| Switch Button | TVI/AHD/CVI/CVBS |
