Description
Interface
| Video Output | Switchable TVI/AHD/CVI/CVBS |
General
| Consumption | Max. 2.4 W |
| Dimension | 161.1 mm × 70 mm × 70 mm (6.34" × 2.76" × 2.76") |
| White Light Range | Up to 20 m |
| Material | Plastic |
| Communication | HIKVISION-C |
| Weight | Approx. 229 g (0.50 lb) |
| Operating Conditions | -40°C to 60°C (-40°F to140°F), Humidity: 90% or less (non-condensing) |
| Power Supply | 12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera. |
| Protection Level | IP67 |
Camera
| Min. Illumination | 0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light |
| Field of View | 3.6 mm, horizontal FOV: 76°, vertical FOV: 41°, diagonal FOV: 90° |
| Light Alarm | Flashing Light Alarm (White Light), Solid Light Alarm (White Light) |
| Shutter Time | PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s |
| Lens | 3.6 mm |
| Lens Mount | M12 |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360° |
| Frame Rate | TVI: 1080p@25fps/30fps CVI: 1080p@25fps/30fps,AHD: 1080p@25fps/30fps CVBS: PAL/NTSC |
| WDR (Wide Dynamic Range) | Digital WDR |
Menu
| Image Mode | STD/HIGH-SAT/HIGHLIGHT |
| Day/Night Mode | Color |
| AE (Auto Exposure) Mode | DWDR, BLC, HLC, Global |
| Noise Reduction | 3D DNR/2D DNR |
| Function | Brightness, Mirror, Sharpness, Anti-Banding, Smart Light |
| White Light | Auto/Off |
| AGC | Yes |
| White Balance | Auto/Manual |
| Language | English |
