Description
Conductor
| Nom.O.D.(mm) | 0.58499999999999996 |
| Material | CCA（Copper content：27%） |
| up | 0.01 |
| down | -0.01 |
Insulation
| Diameter | 1.05±0.05mm |
| Material | Solid HDPE |
Sheath
| Thickness | 0.50±0.05 mm |
| External O.D. | 6.0±0.30 mm |
| Surface | Clean, Frap, Satiation |
| Material | FR-PVC(complies RoHS) |
| Color | White RAL9003 |
Surface Printing
| Letter height | 2.5±0.2mm |
| Color | Black |
| Print error & Space | ≤±0.5%，1m |
Core Color
| 1 Blue & White/ Blue | 2 Orange & White/ Orange |
| 3 Green & White/ Green | 4 Brown & White/ Brown |
Packing
| Packing | Carton |
Packing length
| Packing length | (305±1.5)m |
Rip-cord
| Yes | Drain wire |
Category
| Category | CAT. 6 CCA U/UTP 4x2x23AWG/1 PVC |
Carton dimension
| Carton dimension | 41x41x24cm |
Sheath Physical Properties
| Before Aging Tensile Strength (Mpa) ≥13.5 Elongation(%) ≥150 | Aging Period(℃×hrs) 100℃×24h×7d |
Electrical Characteristics (20℃)
| 1.0-100.0MHz Impedance(Ω) 100±15 100 - 250MHz Impedance(Ω) 100±25 | 1.0-100.0MHz Delay Shew (ns/100m) ≤45 |
