| Image Sensor | 1/2.8” 2MP PS CMOS Image sensor (0.9071 centimeters) |
| Effective Pixels | 1920 (H) × 1080 (V) |
| S/N Ratio | ≥ 55 dB |
| Minimum Illumination | Color: 0.005 lux@F1.6, B/W: 0.0005 lux@F1.6, 0 lux (IR light on) |
| ROM | 128 MB |
| RAM | 256 MB |
| Electronic Shutter | 1/1 s–1/30,000 s |
| Focal Length | 4.8 mm–120 mm |
| Max. Aperture | F1.6–F3.5 |
| Iris Control | Auto |
| Focus Control | Auto, Semi-auto, Manual |
| IR Control | Zoom Prio, Manual, Smart IR |
| IR Number | 3 IR |
| IR | IR Range of 100 Mtr. |
| White Balance | Auto, Indoor, Outdoor, ATW, Manual, Sodium lamp, Natural light, Street lamp |
| Close Focus Distance | 0.1 m–1.5 m |
| Resolution | 2MP (1920 × 1080), 960p (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240) |
| DORI Distance | 1613m (Detect), 646m (Observe), 323m (Recognize), 161m (Identify) |
| Angle of View | H: 58.5°–2.8°, V: 33.2°–1.5°, D: 67.5°–3.2 |
| Gain Control (AGC) | Auto, Manual |
| Back Light Compensation | BLC/ HLC/ WDR(120dB) |
| Optical Zoom | 25x |
| Digital Zoom | 16x |
| Pan/ Tilt Range | Pan: 0° to 360° endless, Tilt: –15° to +90°, auto flip 180° |
| Manual Speed | Pan: 0.1°/s–80°/s, Tilt: 0.1°/s–80°/s |
| Preset Speed | Pan: 80°/s, Tilt: 80°/s |
| Privacy Masking | Up to 24 areas can be set, with up to 8 areas in the same view |
| Special Features | Up to 300 Presets, 5 Pattern, 8 Tour (up to 32 presets per tour), 5 Auto Scan |
| Image Rotation | 180° |
| Bit Rate Control | CBR/VBR |
| Bit Rate | H.265: 512 kbps–5632 kbps, H.264: 1792 kbps–8192 kbps |
| Idle Motion | Preset, Pattern, Tour, Scan |
| Day/Night | Auto (ICR)/Color/B/W |
| Face Detection | Supports face detection, capturing pictures, and face enhancement |
| SMD | SMD 3.0 |
| Auto Patrol | It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets |
| Video Compression | Instastream, H.265, H.264+, H.264, H.264B, MJPEG |
| stream Capability | Triple stream |
| Frame Rate | Main stream: 1080p/960p/720p@(1–25/30 fps) Sub stream 1: D1/VGA/CIF@(1–25/30 fps), Sub stream 2: 1080p/960p/720p@(1–25/30 fps) |
| Audio Compression | G.711a, G.711Mu, G.722.1, G.726, MPEG2-Layer2, G.729 |
| Power-off Memory | Support |
| PTZ Protocol | DH-SD Pelco-P/D (Auto recognition) |
| Image Stabilization | Electronic (EIS) |
| ROI | Support |
| Motion Detection | Support |
| Noise Reduction | 2D DNR, 3D DNR |
| Ethernet | RJ-45 (10/100 Base-T) |
| IVS (Perimeter Protection) | Tripwire, Intrusion, Crossing fence detection, Loitering detection, Abandoned/missing object, Fast moving, Parking detection, People gathering, Vehicle/human alarm classification |
| Protocols | HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, D NS, DDNS, IPv6, 802.1x, SSL, Qos, FTP, UPnP, ICMP, SNMP, SNMPv1/v2c/v3(MIB-2), IGMP, ARP, RTCP, RTP, PPPoE, IP Filter, RTMP, TCP, SMB, NFS, CGI, API, SDK, ONVIF (Profile S & G & T), Unicast/ |
| Storage | FTP, Micro SD card (512 GB), NAS |
| Alarm Linkage | Capture, Preset, Tour, Pattern, Recording, Alarm digital input, Audio, Send email |
| User/Host | 20 (total bandwidth: 64 M) |
| Alarm Event | Motion/Tampering detection, Audio detection, Network disconnection detection, IP conflict detection, Memory card state detection, Memory space detection, Power exception detection |
| Alarm I/O | 2/1 |
| Audio In | 1 channel (LINE IN, bare wire) |
| Audio Out | 1 channel (LINE OUT, bare wire) |
| Browser | IE 7 and later versions, Chrome, Firefox, Safari |
| Smart Phone | iOS, Android, iPhone, iPad |
| Weatherproof Standard | IP66 |
| Operating Temperature | –40 °C to +60 °C |
| Operating Humidity | ≤95% |
| Power Source | 12 VDC/3 A (± 10%) PoE (802.3at) |
| Power Consumption | Basic: 12 W Max.: 20 W (IR light) |
| Dimension | 270.4 mm × Φ160.0 mm |
| Casing | Metal |
| Weight | 2.4 kg |
