<table border="1" cellpadding="8" cellspacing="0" width="100%">
<tr>
<th>Category</th>
<th>Parameter</th>
<th>Specification</th>
</tr>
<!-- Camera -->
<tr>
<td rowspan="14"><b>Camera</b></td>
<td>Signal System</td>
<td>PAL / NTSC</td>
</tr>
<tr>
<td>Frame Rate</td>
<td>
<b>MJPG:</b><br>
1920 × 1080@30fps/25fps<br>
1280 × 960@30fps/25fps<br>
1280 × 720@30fps/25fps<br>
640 × 480@30fps/25fps<br><br>
<b>YUV2:</b><br>
1920 × 1080@5fps<br>
1280 × 960@5fps<br>
1280 × 720@10fps<br>
640 × 480@30fps
</td>
</tr>
<tr>
<td>Resolution</td>
<td>1920 (H) × 1080 (V)</td>
</tr>
<tr>
<td>Min. Illumination</td>
<td>0.1 Lux @ (F1.2, AGC ON)</td>
</tr>
<tr>
<td>Shutter Time</td>
<td>PAL: 1/25 s to 1/50,000 s;<br>NTSC: 1/30 s to 1/50,000 s</td>
</tr>
<tr>
<td>Lens</td>
<td>3.6 mm fixed focal lens</td>
</tr>
<tr>
<td>Field of View</td>
<td>Horizontal: 87°; Vertical: 55°; Diagonal: 95°</td>
</tr>
<tr>
<td>Lens Mount</td>
<td>M8</td>
</tr>
<tr>
<td>Day & Night</td>
<td>24/7 Color Imaging</td>
</tr>
<tr>
<td>Angle Adjustment</td>
<td>Pan: 0°; Tilt: 0° to 35°; Rotation: 0°</td>
</tr>
<tr>
<td>Digital Zoom</td>
<td>Yes</td>
</tr>
<tr>
<td>Cable Length</td>
<td>2 m</td>
</tr>
<tr>
<td>Depth of Field</td>
<td>0.1 m to ∞</td>
</tr>
<tr>
<td>Image Sensor</td>
<td>2 MP CMOS</td>
</tr>
<!-- Interface -->
<tr>
<td rowspan="2"><b>Interface</b></td>
<td>Video Output</td>
<td>USB 2.0</td>
</tr>
<tr>
<td>Audio In</td>
<td>Built-in mic</td>
</tr>
<!-- Operating System -->
<tr>
<td><b>Operating System</b></td>
<td>Supported OS</td>
<td>Windows XP/7/10, Android, Linux, MAC OS</td>
</tr>
<!-- General -->
<tr>
<td rowspan="6"><b>General</b></td>
<td>Operating Conditions</td>
<td>-10°C to 40°C, Humidity: 90% or less (non-condensing)</td>
</tr>
<tr>
<td>Power Supply</td>
<td>DC 5V ± 5% (USB)</td>
</tr>
<tr>
<td>Consumption</td>
<td>2.5 W MAX</td>
</tr>
<tr>
<td>Dimension</td>
<td>47.9 mm × 59.9 mm × 75.4 mm (1.89" × 2.36" × 2.97")</td>
</tr>
<tr>
<td>Weight</td>
<td>Approx. 169.5 g (0.37 lb.)</td>
</tr>
<tr>
<td>Accessory (Packing List)</td>
<td>
Camera × 1<br>
USB Cable × 1<br>
Quick Start Guide × 1<br>
Bracket × 1<br>
Tripod × 1
</td>
</tr>
</table>
