Description
Video/Audio Input
| Two-way audio | 1-ch, RCA (2.0 Vp-p, 1 k Ω) |
| IP video input | 8-ch Up to 8 MP resolution |
Network
| Incoming bandwidth | 80 Mbps |
Decoding
| Decoding format | H.265/H.265+/H.264/H.264+/MPEG4 |
| Synchronous playback | 8-ch |
| Capability | 1-ch @ 8 MP / 4-ch @ 1080p |
| Live view / Playback resolution | 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF |
General
| Power supply | 100 to 240 VAC, 50 to 60Hz, 1.1 A |
| Working temperature | -10 to +55º C (+14 to +131º F) |
| Chassis | 1U chassis |
| Working humidity | 10 to 90 % |
| Dimensions (W × D × H) | 385 × 315 × 52 mm (15.2"× 12.4" × 2.0") |
| Consumption (without hard disk) | ≤ 15 W |
| Weight (without hard disk) | ≤ 2.6 kg (5.7 lb) |
Video/ Audio output
| Outgoing bandwidth | 80 Mbps |
| Recording resolution | 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF |
| HDMI output resolution | 1-ch, 4K (3840 ×2160)/30Hz, 1920 ×1080p/60Hz, 1600 ×1200/60Hz, 1280 ×1024/60Hz, 1280 ×720/60Hz, 1024 × 768/60Hz |
| VGA output resolution | 1-ch, 1920 × 1080p/60Hz,1280 × 1024/60Hz, 1280 ×720/60Hz, 1024 × 768/60Hz |
| Audio output | 1-ch, RCA (Linear, 1 KΩ) |
External interface
| Network interface | 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| USB interface | 2 × USB 2.0 |
Network management
| Network protocols | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI,UPnP™, HTTPS |
Hard disk
| SATA | 2 SATA interfaces |
| Capacity | Up to 6TB capacity for each disk |
POE Interface
| Interface | 8, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
| Power | ≤ 80W |
| Standard | IEEE 802.3 af/at |
