Zoom
Description
Specifications
| Image Sensor | 1/2.8” PS CMOS (0.9071 centimeters) |
| Effective Pixels | 1920 (H) × 1080 (V), 2 Megapixels |
| S/N Ratio | ≥55dB |
| RAM & ROM | 1GB & 4GB |
| Minimum Illumination | Color: 0.005 lux@F1.6 B/W: 0.0005 lux@F1.6 0 lux (IR light on) |
| Max. Aperture | F1.6–F3.5 |
| Focal Length | 4.8 mm–120 mm |
| White Balance | Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural light/Street lamp |
| Focus Control | Auto/Semi-Auto/Manual |
| Close Focus Distance | 0.1m - 1.5m |
| Iris Control | Auto/Manua |
| DORI Distance | 1614m (Detect), 646m (Observe), 323m (Recognize), 161m (Identify) |
| Angle of View | H: 58.5°–2.8°; V: 33.2°–1.5°; D: 67.5°–3.2° |
| Shutter Speed | 1/1s~1/30,000s |
| AGC Control | Auto / Manual |
| Back Light Compensation | BLC / WDR(120dB) |
| Optical Zoom | 25x |
| Digital Zoom | 16x |
| Pan Travel | 0°~360° endless, Pan Speed: 0.1° ~300° /s |
| Tilt Travel | -15° ~ +90°,auto flip 180°, Tilt Speed: 0.1° ~200°/sec |
| Manual Speed | Pan: 0.1° ~300° /s; Tilt: 0.1° ~200° /s |
| Presets | 300 |
| Preset Speed | Pan: 400° /s; Tilt: 300° /s |
| Power-off Memory | Support |
| Bit Rate | H.264: 3 kbps–8192 kbps; H.265: 3 kbps–8192 kbps |
| Special Features | Electronic Defog, Up to 300 Presets, 5 Pattern, 8 Tour (up to 32 presets per tour), 5 Auto Scan |
| IR Range | IR Range upto 150 Mtr. |
| No of IR LEDs | 4 |
| Privacy Mask | Up to 24 areas, and up to 8 areas in the same view |
| Idle Motion | Preset/Tour/Pattern/Scanning |
| Day/Night: IR Cut Filter | Auto (ICR) / Color / B/W |
| Video Compression | H.265; Smart H.264+; H.264; H.264B; H.264H; MJPEG (Sub Stream 1) |
| Encode Strategy | Instastream |
| Streaming Method | Unicast/Multicast |
| Resolution | 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576); CIF (352 × 288) |
| Video Streaming | Main stream: 1080p/1.3M/720p (1–25/30 fps) Sub stream 1: D1/CIF (1–25/30 fps) Sub stream 2: 1080p/1.3M/720p (1–25/30 fps) |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 |
| Two-way Audio | Support |
| Motion Detection | Support |
| ROI | Support |
| SMD | Support |
| Image Rotation | 180° |
| Image Stabilization | Electronic (EIS) |
| Quick Pick | With AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events |
| Audio Streaming | 1/1 channel In/Out |
| Auto Tracking | Support |
| Alarm | 2/1 channel In/Out |
| Alarm Linkage | Capture; preset; tour; pattern; recording; triggering on-off value output; audio; sending email |
| Face Detection | Supports face detection, face bounding box, capturing snapshots, uploading face snapshots, enhancing face images, and selecting a preferred image among a group of snapshots. Attribute Extraction is also supported, where 6 attributes and 8 expressio |
| Alarm Event | Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection; power exception detection |
| Perimeter Protection | Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification |
| Protocols | HTTP; HTTPS; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; IPv6; 802.1x; QoS; FTP; UPnP; ICMP; SNMP; SNMP v1/v2c/v3 (MIB-2); IGMP; ARP; RTCP; RTP; PPPoE; RTMP; TCP; ONVIF (Profile S&G&T); CGI |
| Networking | RJ-45 (10/100Base-T) |
| Browser | IE 7 and later versions, Chrome 42 and earlier versions, Firefox 52 and earlier versions, Safari |
| Memory | Micro SD card (Up to 512 GB) |
| Storage | FTP; NAS |
| User/Host | 20 (total bandwidth 64MB) |
| Smart Phone | iPhone, iPad, Android Phone |
| Operating Temperature | -40°C ~ +70°C (-40 °F to +158 °F) |
| Operating Humidity | ≤95% |
| Weatherproof Standard | IP67; IK10; TVS 6000V lightning proof; surge protection; voltage transient protection |
| Dimension | 332 mm × Φ190 mm |
| Power Source | 24 VDC, 2.5 A (± 25%) PoE+ (802.3at) |
| Power Consumption | Basic: 13 W Max.: 22 W (IR On) |
| Weight | 4.7kg |
